VIKYLIN 8CH 8POE 12MP NVR 4K 8MP 4X Zoom Dome PTZ IP Camera MIC IR Outdoor

VIKYLIN 4K 8MP 4x PTZ MIC IR Network Camera > 1/2.8” Progressive Scan CMOS > 3840 x 2160-20fps > HD 2.8-12 mm Motorized lens > Color: 0.01 Lux -(F2.0, AGC ON)  > B/W:0.004 Lux -(F2.0, AGC ON),0 Lux with IR > 265+,265,H.264,MJPEG > Support PoE > BLC/3D DNR/HLC/WDR > Built-in Mic > IP66  > Support  Human Detection & Vehicle Detection >APP : Videolink(IOS,Android), support download by QR code;Lms >Search Tool: AjDevtool
>Defailt IP:192.168.1.110 >Camera lens: 2.8mm~12mm 4X ZOOM >Warranty: 3 Years >If there is any problem with use, please contact with us at any time. we have very professinal engineer, can help you set online. VIKYLIN 4K 8MP 4x PTZ MIC IR Network Camera > 1/2.8” Progressive Scan CMOS > 3840 x 2160-20fps > HD 2.8-12 mm Motorized lens > Color: 0.01 Lux -(F2.0, AGC ON)  > B/W:0.004 Lux -(F2.0, AGC ON),0 Lux with IR > 265+,265,H.264,MJPEG
> Support PoE > BLC/3D DNR/HLC/WDR > Built-in Mic > IP66  > Support  Human Detection & Vehicle Detection VIKYLIN 8CH 8POE Network Video Recorder 12MP 4K NVR 1SATA
> Up to 8-ch IP camera inputs > Supports IP cameras with a resolution up to 12 MP
> H.265+/H.265/H.264 video formats
> Up to 1-ch 12 MP@30fps/1-ch 8MP@30fps/4-ch 4MP@30fps decoding capacity  > Up to 80 Mbps incoming bandwidth Camera Specifications: Camera Image Sensor 1/2.8”Progressive Scan CMOS Min. Illumination Color: 0.01 Lux -(F2.0, AGC ON)
B/W:0.004 Lux -(F2.0, AGC ON)
0 Lux with IR White Balance Auto/Manual Shutter Speed 1/10 s to 1/10,000 s Day & Night IR Cut Filter Digital Noise Reduction 2D/3D DNR WDR Support Privacy Mask 4 programmable privacy masks Lens Focal Length 2.8-12mm  lens,4 × optical zoom Field of View Horizontal field of view: 96.7° to 31.6° (Wide-Tele)
Vertical field of view: 51.1° to 17.7° (Wide-Tele) PTZ Movement Range (Pan) 0° to 355° Movement Range (Tilt) 0° to 90° Pan Speed Configurable, from 0.1°/s to 40°/s. Preset speed: 40°/s Tilt Speed Configurable, from 0.1°/s to 40°/s. Preset speed: 40°/s Proportional Zoom Yes Power-off Memory Yes Compression Standard Video Compression Main stream: 265+,265,H.264,MJPEG
Sub-stream: 265+,265,H.264,MJPEG 265 Type Baseline profile/Main profile/High profile 265+ Yes Event Basic Event Motion Detection Intelligent detection Human Detection / Vehicle Detection IR IR Distance 30 m IR LED 2PCS Image Max. Resolution 3840 x 2160 Main Stream 20fps-8MP(3840 x 2160)  30fps- (3072 x2048,2592 x1944,2560 x 1440,1920 x 1080) Sub-Stream 30fps-720 x480 /VGA/640x360/480 x360 /CIF Image Enhancement BLC/3D DNR/HLC/WDR Network Network Storage Support Local storage and NFS,NVR,APP Cloud Storage Protocols TCP/IP/IPv4/IPv6/HTTP/RTSP/NFS/DHCP/NTP General Fuction Built-in Mic,Privacy Masks,  Horizon/Vertical Flip,Password Reset,Upgrade API O-N-V-I-F (Profile S, Profile G, Profile T) Simultaneous Live View Up to 20 channels User/Host 3 levels: Administrators, Operators and Users Client Videolink;LMS Web Browser IE 8+ ,Chrome 57.0+, Firefox 52.0+ Interface Network Interface 1 RJ45 10 M/100 M Ethernet, PoE Power 12V DC Audio IN Built-in Mic Audio Out N/A RS485 N/A SD Card slot N/A General Web Client Language 7 languages:
Chinese, English, Russian,  German, Italian, , Turkish, 한국어 Power 12V DC, 1.5 A (Max. 10.9 W, including Max. 4.2 W for IR)
PoE (802.3af), 36 to 57V DC, 0.35 A (Max. 12.2 W, including max. 4.2 W for IR) Working Environment Temperature: -20°C to 60°C (-4°F to 140°F), humidity: ≤ 90% Protection Level IP66 Material Metal Dimension Package: 220 x 200 x 145 mm (8.7'' x 7.9'' x 5.7'') Weight With Package : Approx. 1.22 kg (2.7 lb.) NVR Specifications: Video and Audio IP video input 8-ch Up to 12 MP resolution Incoming bandwidth 80 Mbps Outgoing bandwidth 80 Mbps HDMI output 1-ch, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x 1080/60 Hz, 1920 x 1080/50 Hz, 1440 x 900/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz, 1280 x 720/50 Hz, 1024 x 768/60 Hz VGA output 1-ch, 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1440 x 900/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz, 1280 x 720/50 Hz, 1024 x 768/60 Hz Video output mode HDMI/VGA simultaneous output CVBS output N/A Audio output 1-ch, RCA Audio input 1-ch, RCA Decoding Decoding format H.265+/H.265/H.264 Recording resolution 12MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080P/960P/720P/D1/2CIF/CIF/QCIF Synchronous playback 8-ch Capability 1-ch@12 MP (30 fps)/1-ch@8 MP (30 fps)/4-ch@4MP(30 fps)/8-ch@D1(30 fps) Stream type Video, Video & Audio Audio compression G.711U/G.711A Network Network protocol TCP/IP, DHCP, IPv4, IPv6, NTP, RTSP HTTP, HTTPS Network interface 1, RJ-45 10/100 Mbps self-adaptive Ethernet interface PoE Interface 8, RJ-45 10/100 Mbps self-adaptive Ethernet interface Power ≤ 90 W Supported standard IEEE 802.3 af/at Auxiliary Interface SATA 1 SATA interface Capacity Up to 14 TB USB interface 2 × USB 2.0 General Power supply 52 VDC, 1.8 A Consumption ≤ 3 W (without HDD and PoE off) Working temperature -10 °C to 55 °C (14 °F to 131 °F) Working humidity 10% to 90% Dimension (W × D × H) 260 × 210 × 43 mm (10.2" × 8.3" × 1.7") Weight (without HDD) ≤ 1 kg (2.2 lb)
