Product Feature
4MP WDR IR Bullet Network Camera IPC-HFW2431R-ZS-IRE6 OEM 2.7~13.5mm varifocal lens
> 1/3” 4Megapixel progressive CMOS
> H.265 & H.264 dual-stream encoding
> 20fps@4M(2688×1520)&25/30fps@3M(2304×1296)
> WDR(120dB), Day/Night(ICR), 3DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> Micro SD card slot, up to 128GB
> 2.7~13.5mm varifocal lens
> Max IR LEDs Length 60m
> IP67, PoE
Product Specification:
Camera
Image Sensor:
1/3” 4Megapixel progressive CMOS
Effective Pixels:
2688(H) x1520(V)
RAM/ROM:
512MB/32MB
Scanning System:
Progressive
Electronic Shutter Speed:
Auto/Manual, 1/3~1/100000s
Minimum Illumination:
0.03Lux/F1.4( Color,1/3s,30IRE)
0.3Lux/F1.4( Color,1/30s,30IRE)
0Lux/F1.4(IR on) >>> This camera is Dahua OEM Version, remove Dahua logo on the box and come with yellow box. support OEM upgrade.(need to contact us for new firmware)All function and quality are the same as Dahua Original. >>> All the items are with 3 years warranty, if there is any problem after purchased, please contact us for help.
> Dah APP: iDmss( iOS), gDmss( Android), Smartpass
> Search Tool: Config Tool (search device and change IP address if needed)
> Default IP: 192.168.1.108
> Camera lens: 2.7-13.5mm
Installation
Dimension
Following figures are for reference only, and the actual product shall prevail.
Installing SD Card (Optional)
Pull the power plug off before installing or removing the SD card.SD card is not included.
Reset Button
Press and hold the RESET button for at least 5 seconds to reset the camera.
Product Feature
4MP WDR IR Bullet Network Camera IPC-HFW2431R-ZS-IRE6 OEM 2.7~13.5mm varifocal lens
> 1/3” 4Megapixel progressive CMOS
> H.265 & H.264 dual-stream encoding
> 20fps@4M(2688×1520)&25/30fps@3M(2304×1296)
> WDR(120dB), Day/Night(ICR), 3DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> Micro SD card slot, up to 128GB
> 2.7~13.5mm varifocal lens
> Max IR LEDs Length 60m
> IP67, PoE
Returns Accepted for this item if it's within 30 Days
